XD 844

Bottom View
  • 8" deep bottom ultra thick stamped basket with perimeter vents
  • Coated strong kevlar enhanced nonpress paper cone
  • EROM high excursion foam surround
  • 2" long throw hi-temp voice coil
  • 2-layer black conex spider
  • double-stacked 90oz magnet
  • Rubber gasket and rubber magnet boot
  • 10# power cable
  • Dual 4ohm impedance
  • 300W rms power handling



   Imp Dcr L Fs SD BL Qms Qes Qts EBP n SPLo Vas Cms Mms Mmd Xmax OD MD BC MHd OH
MODELs Ohm ohm Mh Hz msqM TM       Hz % dB L mmm/N g g ±mm mm mm mm mm mm
XD-8 8 6.8 4.72 44.765 20.106 16.978 4.785 0.693 0.605 74 0.137 83.4 6.95 121.08 104.4 102.76 11.5 214 120 182 Φ199X8XΦ5.5XΦ8 138
XD-8 2 1.58 1.116 45.303 20.106 8.035 5.465 0.693 0.615 74 0.128 83.2 7.121 124.06 102.5 100.85 11.5 214 120 182 Φ199X8XΦ5.5XΦ8 138
Diameter A (mm)Diameter B (mm)Diameter C (mm)Diameter C (mm)Depth E (mm)Depth F (mm)Depth G (mm)Total Height H (mm)M-Vd (L)NW (Kg)
217 φ199x8xφ5.2 185 161 60 15 130 154 2.061 6.85
